Goodway Smart Band with Heart Rate and Blood Oxygen B5

Key Capabilities & Business Benefits

• Performance: Real-time monitoring of heart rate, blood oxygen, and pressure detection.

• Power & Runtime: 18mAh polymer lithium battery supports 3–5 days of use with 2-hour charging.

• Durability: Daily waterproof design supports swimming and diving.

• Accuracy: Equipped with HX3918 heart rate sensor and SC7A20H G-sensor for precise measurements.

• Connectivity: Bluetooth 5.3 for stable wireless connection.

• Convenience: Magnetic charging cable with SMT protect IC for safe charging.

Technical Specifications

• Main Control (CPU): OM6626B

• Material: Zinc alloy + epoxy resin

• Connectivity & Protocols: Bluetooth 5.3

• Battery & Power: 18mAh polymer lithium battery with protection IC

• Working Time: About 3–5 days

• Charging Time: 2 hours

• Charging Method: Magnetic charging cable with SMT protect IC

• Charging Requirement: 1A or less

• Sensors:

  • Heart rate sensor: HX3918

  • G-sensor: SC7A20H

• Waterproof Level: Daily waterproof, supports swimming and diving

• App: Nx Wear (Android 6.0+ / iOS 11.0+)

• Functions:

  • Heart rate detection

  • Blood oxygen test

  • Pressure detection

  • Heart rate variability

  • Female physiological cycle tracking

  • Shake to take photo

  • Multiple sport modes

  • Sleep monitoring (sleep time & quality)

  • Step counter

  • Data synchronization with APK/APP

• Operating Environment:

  • Operating temperature: 0 – 45°C

  • Storage temperature: –10 – 55°C

  • Working humidity: 5% – 95% (non-condensing)

• Protection Standards:

  • Electrostatic protection: contact ±6KV, air ±10KV

  • Surge protection: 12V

  • Drop resistance: compliant with GB/T 2423.8 standard

  • Vibration resistance: compliant with GB/T 2423.10 standard

  • Charging temperature protection: 45°C

Product Size

• Device Size: 43 × 9.6 × 5.6 mm

• Gift Box Size: 92 × 90 × 48 mm

• Carton Size (100 pcs): Standard export carton

Packing Weight

• Net Weight: 12 g

• Gross Weight (with gift box & accessories): 116 g

• Carton Weight (100 pcs): About 12.2 kg
